Completions and Commissioning

Vecta uses a refined gated completions and commissioning model to help ensure consistent and reliable start-up of your facility and avoid costly and time consuming failures of critical components.

Commissioning Workflow2.png

Vecta employs personnel at all levels of the completions and commissioning organisational hierarchy and is ready to deploy some or all roles to your next project:

Commissioning Org Chart.png

Vecta can supply a complete team to offer a turnkey completions and commissioning experience or integrate with an existing team to fill positions as necessary.

Handover Process

Mechanical Completion (MC) Certificate:

Issued by the constructor/turnaround management for the transfer of responsibility from Construction to Commissioning.

  • All work and allocated Mechanical Installation Test Procedures for the Sub-System have been completed

  • The Sub-system is ready for pre-commissioning activities to take place

  • All mechanical defects preventing commissioning (Punch A’s) are complete

Punch List Categorisation

  • A – Critical items in terms of safety or operability that must be completed before pre-commissioning.

  • B - Items allowed during pre-commissioning, they must be completed prior to Ready for Commissioning Certification.

  • C – Items allowed during commissioning; they must be completed prior to Ready for Operations.

  • D – Defects identified of a non-critical nature. To be added to operations’ maintenance system.


Ready for Commissioning (RFC) Certificate:

The System is ready for Commissioning activities to take place in a safe manner.

  • All pre-commissioning checks and Installation Test Procedures for the System have been completed

  • Risk and readiness review completed

Ready for Start-Up (RFSU) Certificate:

Each system has been commissioned to the extent possible without full operation.

  • Any outstanding “Punch C” work/exceptions will be documented on this certificate. This Certificate will state that the system is ready for start-up.

  • The system is ready for safe operation

  • A Pre-start safety review must be completed and actioned prior to full plant start-up

Ready for Operations (RFO) Certificate:

Transfer of responsibility between Commissioning and Operations, stating that:

  • All commissioning activities for all systems have been completed.

  • All related equipment functions in accordance with the Project specifications and requirements.

  • All changes have been registered and closed out.

  • All safety related and performance critical Punch-lists (A’s, B’s & C’s) have been cleared and closed out

  • Requirements of related Performance Standards have been met.


Completions


Vecta will work closely with your construction / turnaround team to ensure that work is completed as specified and handed over to the commissioning team in an agreed manner to ensure a smooth transition.

Desktop Work

  • Commissioning Sequencing, Schedules developed

  • Commissioning Systems & Sub-systems

  • Procedures developed to match separately commissionable units

  • Designed to match turnaround completion & Pre-commissioning scopes

  • Commissioning Procedures assessed in HAZID Workshop

  • Temporary equipment hire requirements assessed

  • Spares procurement

  • MDR Acceptance

  • Vendor contracts

  • Sub-consultant contracts

  • MC Certificates generated by sub-system

Field Work

  • All equipment verified in place

  • Filters, packing, internals installed

  • Flanges QA checked

  • Punch List A items rectified

  • Mechanical system walkdown

Commissioning Management Systems

Vecta uses an integrated completions & commissioning management system (CCMS) which keeps up to date information on:

  • Storage of reference data such as construction Inspection & Test Plans (ITP), Commissioning Field Test Plans (FTP), Project-specific requirements

  • Storage of Engineering documentation (engineering registers and loops and circuit drawings)

  • Sub-systemisation of plant assets are allocated as tagged items

  • Set up and management of punch list register and approval process for changes (e.g. changes to tag allocation to subsystems)

  • Creation of equipment specific ITR’s and other inspection documents

Vecta’s experienced supervisors and technicians will systematically assess all plant components to ensure their independent functionality during pre-commissioning.

Desktop Work

  • Notice of Energisation used to authorise hazardous voltages, pressures or fluids introduction

  • Vendor interface management

  • Sub-consultant interface management

  • Engineering change management

  • First fills procurement

  • Spares, repairs procurement

  • ITR’s input to commissioning management system

  • SIMOPS Management

  • Risk and readiness review

  • Commissioning procedures developed

Pre-Commissioning


Field Work

  • Loop testing

  • Cause & Effects testing

  • ESD Dry Run

  • Uncoupled motor runs

  • Dry, coupled motor runs

  • Valve stroking

  • Relief valve testing

  • Hazardous area certification

  • Critical document as-building

  • Utilities: Air, Power etc. online

  • Safety Systems e.g. showers testing

  • Equipment preservation

  • Punch List B items rectified

Commissioning

Vecta’s commissioning engineers will integrate with your operations team to ensure safe and effective commissioning of all equipment and system handover with operational confidence.

Desktop Work

  • Commissioning Sequence optimisation to meet dynamic challenges

  • SIMOPS Management

  • Procedure isolations and permit management

  • Vendors on site

  • Sub-consultants on site

  • Engineering change management

  • Commissioning change management

  • Pre-start safety review

  • Operations handover

Field Work

  • Leak testing

    • Ensure flanges are tight

    • Inert vessels for hydrocarbon introduction

  • Verify Isolations

    • Relief valves online

    • Other safety critical equipment ready

  • Fluid introduction / 1st Fills

  • Wet commissioning

  • Full ESD & Blowdown testing

  • Introduction of hydrocarbons

  • System alignment walkdown for start-up

  • Punch List C items rectified

Start-Up


Vecta’s commissioning team will facilitate initial start-up and performance testing of the whole facility. They will approve and deliver a complete commissioning dossier containing the full commissioning history and outcomes.

Desktop Work

  • As-built handover

  • Operations support

  • Ready for Operations Certification

  • Customer & regulator notification

  • CCMS Data transfer

  • Training sessions

Field Work

  • Full plant operation

  • Production gas flowing

  • Verify all systems operating in concert

  • Product on spec

  • Control loop tuning

  • Performance testing

  • Verify plant production performance

  • Contract obligations met

  • Turndown achieved

  • Punch List D items rectified as required

Key Support Documents

  • Commissioning Execution Plan

  • Commissioning Sequencing

  • Commissioning Schedule

  • Commissioning HSE Management Plan

  • Project Risk Management Plan

  • Management of Change

  • Safety Standards

  • Production / Reliability Standards

  • Operating Procedures

  • Interface Management Plan

    • Commissioning

    • Operations

    • Community

    • Customers

    • Vendors

    • Sub-contractors

  • Engineering Documents

  • Technical Queries & Design Changes Procedure

  • Override and Bridge Register

  • Regulatory Approvals Plan

  • As-building procedure

  • MC ITR’s

  • PC ITR’s

  • Hazardous Area Inspections

  • HAZOP Closeout Report

  • Commissioning Action Register

  • Punchlist

  • Commissioning scaffold plan

  • Performance Standards
